Murphy PV101-C-M02顯示器
Murphy PowerView 型號 PV101 是 Murphy 在 J1939 MurphyLink 系列組件中配備的一款功能強大的顯示器，它提供了一個查看現代電子控制發動機和傳動系統工作情況的窗口。 PV101 顯示器是一種多功能工具，它能夠讓設備操作員查看多種標準發動機和傳動系統參數，以及當前的和存儲的故障代碼。顯示器可以每屏顯示一個參數，也可以采用四分屏方式同時顯示四個參數。診斷功能包括一些故障代碼，以及對大多數常見故障的文字說明。增強警報指示功能具有高亮度警報和關機指示燈（琥珀色和紅色）。 PV101 多語言選項除已有語言（英文、西班牙文、法文、德文和意大利文）外，還新增了俄文、中文和日文型號。
-顯示SAE J1939標準和自定義參數信息
-可自定義多屏幕參數顯示，可選多種語言
-顯示器可視溫度范圍-29 - 85度
-顯示SAE J1939故障診斷代碼及文本解讀信息
-符合歐四標準
-可選設置軟件
- Murphy PV101-C-M02
- Part No.: PV101-C-M02
- Language: Chinese
- Operating Voltage: 8 VDC minimum to 32 VDC maximum with optional PVM gages
- Reversed Polarity: Withstands reversed battery terminal polarity indefinitely within operating temperatures
- Operating Temperature: -40 to 85°C (-40° to 185°F)
- Display Temperature: -29 to 85°C (-20° to 185°F)
- Storage Temperature: -40 to 85°C (-40° to 185°F)
- Environmental Sealing: IP68, ±5 PSI (± 34.4 kPa)
- Power Supply Operating Current: (@ 14VDC) 52 mA min; 300 mA max ? (@ 32VDC) 1A max (with LCD heater)
- CAN Bus: SAE J1939 compliant
- Case: Polycarbonate / polyester
- Auxiliary RS485 Communications Port: User configurable as Modbus MASTER or Modbus RTU SLAVE ? MASTER ACTIVE (default) drives optional PVA or PVM gages ? SLAVE ACTIVE offers user adjustable communication parameters
- Resistive Input: (user selectable as one of the following) Backlighting Potentiometer: 1 K Ohm, 1/4 W ? Murphy Fuel Sender: 33 Ohm full, 240 Ohm empty set standard from factory for use with Murphy fuel sender. Programmable for use with non-Murphy fuel senders
- Clamp: PBT
- Connectors: 6-pin Deutsch DT Series
- Maximum Panel Thickness: 3/8 inch (9.6 mm)
- Shipping Weight: 1 Lb. (450 g.)
- Shipping Dimensions: 5 x 6 x 6 in. (127 x 152 x 152 mm)
